MTP® Trunk Cables are designed for high-density cabling, saving space and making them easy to manage. Precision MT ferrules and components are used to ensure higher precision during optical fiber docking. It complies with MPO standards and has better performance levels. You can choose up to 144 cores.
MPO/MTP® Trunk Cables 144 Fibers
| Number of cores : | 24F~144F |
| Grinding method : | SM: UPC/APC ; MM: UPC/PC |
| Cable outer cover : | PVC/LSZH/OFNP |
| Fiber type : | G657A1/OM1/OM2/OM3/OM4/OM5 |
| Wave length : | SM: 1310/1550nm ; MM: 850/1300nm |
| Branch Cable Diameter : | 3.0mm |
| Operating temperature : | -25°C~ +70°C |
| Storage temperature : | -40°C~ +85°C |
Connectivity Solutions
Features
● Optimize cable management to speed deployment and increase flexibility and manageability, reducing installation costs
● Suitable for 100G QSFP+ SR4/CSR4 and 400G QSFP28 SR4 data center high-density applications
● MTP® connectors are fully compliant with MPO standards and provide higher performance levels compared to universal MPO connectors
